ITW switches 旋转开关 76-9470/439088G、76-9470/439088R

76-9470/439088G、76-9470/439088R

旋转开关, 2路, 1位, 10 A, 250 V, 76-94

马上咨询

客服电话 13818757930

Additional information

Switch Type	Rotary
Switch Operation	Maintained
Actuator Type	Rotary
Actuator / Cap Color	Green
Case Color	Black
Contact Configuration	SPDT-NC-DB
Operating Force (Nom)	7N / 25.2ozf
Contact Material	Fine Silver
Contact Voltage AC Nom	250V
Contact Voltage DC Max	Not Applicable
Contact Current AC Max	10A
Contact Current DC Max	Not Applicable
Illuminated	Non Illuminated
Illumination Color	Not Applicable
Illumination Voltage	Not Applicable
Switch Mounting	Threaded Bushing
Panel Cutout (H x W)	22 x 20
IP Rating	IP67
Legend	Not Applicable
Operating Temperature Range	-40°C to +125°C
Standards Met	Not Applicable
Mechanical Life	50000
Electrical Life	100000
Product Series	76-94
